Descripción
Descripción
CAMARA HIKVISION IP 4MPX BULLET, 2.8MM FIXEDLENTE, IP67, 30M IR, DWDR, FRONT COVER: METAL, BACK COVER & BRACKET: PLASTIC, 1/3″ PROGRESSIVE CMOS, ICR, 2560X1440:20FPS(P)/(N), 2304X1296:25FPS(P)/30FPS(N), H.265+/H265/H.264+&H.264, 3D DNR, BLC, IR RANGE: UP TO 30M, DC12V & POE,SUPPORT MOBILE MONITORING VIA HIK-CONNEC *POWER SUPPLY NO INCLUDED
Características
Camera
– Image Sensor: 1/2.8″ progressive scan CMOS
– Min. Illumination: Color: 0.01Lux @(F1.2,AGC ON),0 Lux with IR
– Shutter Speed: 1/3s to 1/100,000 s, support slow shutter
– Lens: 2.8 mm @F2.0, horizontal field of view 105.8°, 4 mm @F2.2, horizontal field of view 83.6°
6 mm @F2.0, horizontal field of view 55°
– Lens Mount: M12
– Day &Night: IR cut filter with auto switch
-Axis Adjustment (Bracket): Pan: 0° to 360°, tilt: -90°to 90°, rotation:0° to 360°
– DNR(Digital Noise Reduction): 3D DNR
– WDR (Wide Dynamic Range): Digital WDR
Compression Standard
– Video Compression: Main stream: H.265+/H.265
Sub stream: H.265/H264/MJPEG
– H.265 Type: Baseline profile/Main profile
– Video Bit Rate: 32 Kbps to8 Mbps
– Max. Resolution: 2560X1440:20FPS(P)/(N), 2304X1296:25FPS(P)/30FPS(N)
– Main Stream: 50Hz: 25fps @(1920 × 1080, 1280 × 960, 1280 × 720)
– Max. Frame Rate: 60Hz: 30fps @(1920 × 1080, 1280 × 960, 1280 × 720)
– Sub-stream: 50Hz: 25fps @(704 × 576, 640 × 480, 352 × 288,320 × 240)
– Max. Frame Rate: 60Hz: 30fps @(704 ×480, 640 × 480, 352 × 240,320 × 240)
– Image Settings: Brightness, saturation, contrast, sharpness are adjustable via web browser or client software
– Day/Night Switch: Support auto, scheduled
– Others: Mirror, BLC (area configurable), region of interest (support 1 fixed region)
Network
– Network Storage: NAS (NFS,SMB/CIFS)
– Detections: Motion Detection
– Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour
– Standard: ONVIF(PROFILE S,PROFILE G),PSIA,CGI,ISAPI
– General Function: Anti-flicker,heartbeat, mirror, password protection, privacy mask,watermark, IP address filter
Interface
– Communication Interface: 1 RJ45 10M/100M self-adaptive Ethernet port
General
– Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing)
– Power Supply: 12VDC± 25%, PoE (802.3af)
– Power Consumption: Max. 5 W/6.5 W (PoE)
– Ingress Protection: IP67
– IR Range: Up to 30 m
– Dimensions: 69.1 mm ×66 mm × 172.7 mm ( 2.7″× 2.6″×6.8″)
– Weight: 500 g (1.1 lb.)
Soporte
3 AÑOS DE GARANTÍA en todos los productos Hikvision, ofrecida por el fabricante, contra defectos de fabricación y/o vicios del material que afecten al normal funcionamiento del mismo
