DOMO PTZ ANALOGICO HIKVISION 2MPX (1920X1080) EXTERIOR (IP66) CON IR 100 METROS DE INTENSIDAD VARIABLE EN FUNCIÓN DEL ZOOM. SENSOR DE 2MPX CMOS DE ESCANEO PROGRESIVO. ZOOM ÓPTICO DE 23X (4~92MM). ZOOM DIGITAL DE 16X. 256 PRESET, 8 PATRULLAS Y HASTA 32 PRESET POR PATRULLA. ILUMINACIÓN MÍNIMA 0,05 LUX EN COLOR Y HASTA 0,005 LUX EN B/N CON AGC ACTIVADO.MÁSCARAS DE PRIVACIDAD (HASTA 8 MÁSCARAS). DIGITALWDR, RELACIÓN S/N >= 50 DB, AGC, BLC, 3D DNR.CONTROL MULTIPROTOCOLO VÍA RS485 (HIKVISION, PELCO-P, PELCO-D, AUTODETECCIÓN). ALIMENTACIÓN: 12 VCD / 18 W(MAX). DIMENSIONES: 164.5MM (Ø) × 295MM (AL).PESO 2KG.
Características
Camera
– Image Sensor: 1/2.8″ Progressive Scan CMOS
– Effective Pixels: 1920(H)x1080(V)
– Signal System: PAL/NTSC
– Minimum Illumination: Color: 0.005Lux@( F1.4,AGC ON); B/W: 0.001Lux@( F1.4,AGC ON), 0 Lux with IR
– White Balance: Auto / Manual / ATW / Indoor / Outdoor- AGC: Auto/Manual
– BLC: ON/OFF
– WDR: ≥ 120 dB
– Shutter Time: 1-1/10,000s
– Day& Night: ICR
– Digital Zoom: 16X
– Privacy Masking: 8 privacy masks programmable
– Auto Focus: Auto / Semi-automatic / Manual
Lens
– Focal Length: 4-120mm, 25x- Angle of View: 49-2.2 degree(Wide-Tele)
– Minimum Working Distance: 10~1,000mm(Wide~Tele)
– Aperture Range: F1.4-F3.5
Pan & Tilt
– Pan Range: 360°endless
– Zoom Speed: Approx.3s(Optical Wide~Tele)
– Tilt Range: -15°-90° (Auto Flip )
– Tilt Speed: Tilt Manual Speed: 0.1°~80°/s, Tilt Preset Speed: 80°/s
– Proportional Zoom: Rotation speed can be adjusted automatically according to zoom multiples
– Number of Preset: 256
– Patrol: 10 patrols, up to 32 presets per patrol
– Pattern: 5 patterns, with the total recording time not less than 10 minutes
– Power loss recovery: Support
– Park Action: Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan
– PTZ Position Display: ON/OFF
– Freeze Frame: Support
Infrared
– IR irradiation distance: 100m
– IR Intensity: Automatically adjusted depending on the zoom ratio
General
– RS-485 Protocols: HIKVISION, Pelco-P, Pelco-D, self-adaptive
– Menu Language: English
– Power Supply: 12V DC- Power
– Consumption: Max.20W- Working
– Temperature/Humidity: -30 °C-65°C(-22°F-149°F)- 90% or less
– Protection Level: IP66 standard (outdoor dome)
– TVS 4,000V lightning protection, surge protection and voltage transient protection
– Mounting: Various mounting modes optional
– Dimensions: Φ164.5(mm)×295(mm)
– Weight (approx.): 2Kg (4.41Ibs)
– Mount Option: Long-arm wall mount: DS-1602ZJ; Corner mount: DS-1602ZJ-corner;- Pole Mount: DS-1602ZJ-pole; Power box mount:DS-1602ZJ-box; Swan-neck mount: DS-1619ZJ
